ELX16-240 APPENDIX
74 2003.09.06 (v 1.0) Rugged CCTV.
Event Triggered Video Data Preservation Overwrite prevention of Event triggered data
Event Log Recording Log archiving on HDD
Log search & monitoring via Network
Data (Video & Audio Clip) Back -u p
Data Copy (Max. 1 minute ’s video clip)
External HDD: IEEE1394 (FireWire) or USB
PnP Memory Stick: USB port
VHS Video Tape: Video output port for VCR
Backup Notification: Daily / Weekly / Monthly
PnP USB storage (Compact Flash, Smart Media,
Memory Stick, SD Card)
Displaying Performance Frame Rate on CCTV Monitor: Max. 120fps
Frame Rate on PC: Max. 60ips
Display Channel: Quad, Aut o Sequential
Misc.
Play speed: 1x, 2x, 4x, 8x, 16x (FDW & REV)
Supports Step -Forward, Step -Reverse.
Instant data access based on time and event log
Digital Zoom 2 times digital zoom (Live & Playback Mode)
Event Triggered Pop -up Video Triggered by motion detection or sensor input
PTZ Control Ports: RS232(2) , RS485/RS422(2)
Local User Front panel push button & IR Remote
(controls IP video channels as well)
Remote User On -the-screen PTZ control on PC
Preset: 8 points per channel
Group: 1 group per channel
Return Home Position ’ support
Sensor Inputs and Relay Outputs Software -controlled 16 sensor input s
Software -controlled 4 relay out put s
