Basic Configuration ELX16-240
Rugged CCTV.
2003.09.06 (v 1.0) 47
5.6. Monitor
This menu is to set display image on monitor A & monitor B.
Alarm Pop-up (sec)
To set alarm pop-up screen. Pop -up duration time can be set between 5 and 10 seconds. If setting as
“Keep”, pop-up screen keeps holding. In order to cancel Keep mode, press another channel button.
Seq. Switching(sec)
To set sequence time between 1 and 60 seconds.
If channel 1 pops up and channel 2 also pops up during pop -up hold time, screen is changed to quad-
split screen and channel 1 and 2 are shown. And the pop -up hold time is extended automatically. (Up to
8 channels)
User Sequence Configuration
To set user sequence mode.
