5.1.2. Recording
Its recording values are applied to all 16 channels for all time periods.
- Press [MENU] button and select to “Recording “ from the “Quick Setup ” tab. Configuration Status Displays the recording set up status. If recording is configure d with the Quick Setup, “Macro Setup ” will be displayed. If recording is configured with the “Normal” and “Alarm” recording, “Custom Setup” will be displayed. When all 16 analog cameras' normal recording conditions are set identically, the status is marked as 'Macro Setup'. Otherwise, it is marked as 'Custom Setup'. Channel Status When “On,” all eight analog channels will record based on the Quick Setup settings.
- Press [MENU] button and select to “Recording “ from the “Quick Setup ” tab.
Configuration Status
Displays the recording set up status. If recording is configure d with the Quick Setup, “Macro Setup ” will
be displayed. If recording is configured with the “Normal” and “Alarm” recording, “Custom Setup” will
be displayed.
When all 16 analog cameras' normal recording conditions are set identically, the status is marked as
'Macro Setup'. Otherwise, it is marked as 'Custom Setup'.
Channel Status
When “On,” all eight analog channels will record based on the Quick Setup settings.
