WatchIN Installation Manual 2
Relay Mode Installation
Introduction
RISCO Group's Dual Technology Grade 3 Industrial detector, WatchIN, is a unique detector with
signal processing based on two Passive Infrared (PIR) channels and two Microwave (MW)
channels. The detector can operate as a regular relay detector connected to any control panel, or
as a BUS accessory when connected to RISCO Group's ProSYS control panel via the RS485
BUS, thus having unique remote control and diagnostic capabilities.
The instructions describe herein, describe the WatchIN in Relay & BUS mode. For detailed
information regarding BUS mode installation, refer to BUS Mode installation chapter, page 15.
Mounting
Mounting Considerations
WatchIN Detector -
Optional Installation
Height:
2.4m – 3.7m
(7'10"-12'2")
Typical Height: 2.4m (7'10")
Default Lens: Wide angle 25m (88') 90°
(RL325)
2.4m
(7'10")
25m (88')
For optimum detection, select a location that is likely to intercept an intruder moving across
the coverage pattern at a 45° trajectory.
