WatchIN Installation Manual 14
Technical Specification
Electrical
Current consumption (Relay Mode)
45mA at 12 VDC (Stand by)
60mA at 12 VDC (MAX with LED ON)
Current consumption (BUS Mode) 30mA at 12 VDC (Stand by),
45mA at 12 VDC (MAX with LED ON)
Voltage requirements 9-16 VDC**
Alarm contacts 30 VDC, 1A
AM contacts 24 VDC, 0.1A
Physical
Size:
LxWxD
215 x 95 x 85mm
(8.5" x 3.75" x 3.35")
Weight 0.632 Kg (1.4lb)
Environmental
RF immunity
40V/m (30MHz to 2GHz)
Operating/Storage temperature 0°C to 49°C (32°F to 120°F)
* PIR technology is limited in rough environmental conditions.
** Use a 5A max power supply, using safety-approved wires with a minimum gauge of 20AWG.
Ordering Information
Standard Units
Part Number Description
RK325DT WatchIN DT 10.525GHz / 10.587GHz / 9.9GHz + Swivel
The detector contains a standard swivel and a replacement barrier lens (P/N engraved on the Lens -RL327B)
Accessories
Part Number Description Weight
RA300B Barrier Swivel Kit 0.1 Kg (0.23 lb)
RA300P Pole Adaptor Kit 0.25 Kg (0.55 lb)
RA300C Conduit Adaptor Kit 0.6 Kg (1.27 lb)
RA300SC Swivel Metal Conduit Adaptor 1Kg (2.2 lb)
RA300HS WatchIN Demo - -
Camera Accessories
Part Number Description
WatchOUT VC1 Camera Cover Adaptor 1
WatchOUT VC017 NTSC / PAL Narrow Camera For WatchIN
WatchOUT VC053 NTSC / PAL Wide Camera For WatchIN
WatchOUT VCPS 220V / 120V PAL Camera Power supply
UL Compliance Section
To comply with UL standards, note the following:
♦
When the detector is connected to the BUS of the ProSYS panel, the detectors are to be
powered from either the ProSYS panel (V7.55) or a listed compatible burglar alarm power
supply that has an output voltage range that does not exceed 9-16 VDC, has a minimum of 4 hours
of standby power, and is suitable for mercantile use.
♦
A dead zone of 2 ft should be considered during installation.
♦
The camera option is not UL listed.
♦
0.6 power factor inductive load can be used on the relays.
♦
Only RK325DT version 10.525GHz is UL approved.
♦
The vibration option is not incorporated on UL listed products.
♦
The maximum range was tested and evaluated by UL with the trimmer set to maximum MW and
ACT settings for PIR.
♦
On power up the detector is not operational for the first 20 seconds.
♦
The detector should be tested by the installer at least once a year.
