Part Names and Functions
15
Rear
9 Interface cover
open/close switch Opens and closes the interface cover. s p.193
10 Ceiling mount
attachment points
(Four points) Attach the optional ceiling mount here when
suspending the projector from a ceiling. s
p.152 ,
p.197
Name Function
Name Function
1 Air exhaust vent
(Lamp cover) Exhaust vent for air used to cool the projector
internally. Also, open this cover to replace the
projector's lamps.
Caution
Do not place objects that may become warped or
otherwise affected by heat near the air exhaust vent
and do not put your face or hands near the vent while
projection is in progress.
2 Rear foot When set up on a desk, turn to extend and retract
to adjust the horizontal tilt.
The rear adjustable feet can be removed when the
projector is installed on a ceiling. s
p.194
3 Lamp cover open
tab Use these tabs to open the lamp cover. s p.119
