106
R-09HR configuration settings
The memory card usage and protect setting can be checked.
fig.sdutl-e.eps_80
1.
Select “SD Card” from the
Use the [PLAY Button ] and [STOP Button ] to select
“SD Card,” then press the [REC Button].
fig.information-e.eps_80
2.
Select “Information.”
Use the [PLAY Button ] and [STOP Button ] to select
“Information,” then press the [REC Button].
The information is displayed.
When finished with the settings, press the [MENU button] to return
to previous screens, in order.
Displaying SD memory card information (Information)
Displayed
information
Total (total capacity)
Remain (free space)
Write Protect (protect on/off)
Move the
cursor
up or down
Enter
Move the
cursor
up or down
Enter
