100
R-09HR configuration settings
Sets whether to monitor the input sound through headphones while recording.
fig.inputsetting-e.eps_80
1.
Select “Input Setup” from the
Use the [PLAY Button ] and [STOP Button ] to select
“Input Setup,” then press the [REC Button].
fig.setrecmonitor-e.eps_80
2.
Set monitoring with the “Rec Monitor Sw.”
Use the [PREV button ] and [NEXT button ] to set
whether to monitor the input sound through the
headphones during recording by changing the setting for
Rec Monitor Sw.
When finished with the settings, press the [MENU button] to return
to previous screens, in order.
If you monitor the sound through headphones while recording,
there will be a 6 ms delay compared to the actual sound, but this
is not a malfunction.
Setting whether to monitor sound while recording
(Rec Monitor Sw)
Setting
OFF (no monitoring)
ON (monitoring)
Move the
cursor
up or down
Enter
Change
the value
