ROC827 Instruction Manual

Issued Mar-06

Input/Output Modules

4-1

Chapter 4 – Input/Output Modules

This chapter describes the Input/Output (I/O) modules used with the
ROC827 and expandable backplanes and contains information on
installing, wiring, and removing the I/O modules.

In This Chapter

4.1 I/O

Module

Overview ...............................................................................4-1

4.2 Installation................................................................................................4-3

4.2.1 Installing an I/O Module .................................................................4-4
4.2.2 Removing an I/O Module ...............................................................4-5
4.2.3 Wiring I/O Modules ........................................................................4-6

4.3 Analog

Input Modules ..............................................................................4-6

4.4 Analog

Output Modules ...........................................................................4-8

4.5 Discrete

Input Modules ............................................................................4-9

4.6 Discrete

Output Modules .......................................................................4-10

4.7 Discrete

Output

Relay Modules.............................................................4-11

4.8 Pulse

Input Modules ..............................................................................4-12

4.9 RTD

Input

Modules................................................................................4-14

4.9.1 Connecting the RTD Wiring .........................................................4-15

4.10 J and K Type Thermocouple Input Modules..........................................4-16
4.11 Related

Specification Sheets.................................................................4-21

4.1

I/O Module Overview

The I/O modules typically consist of a terminal block for field wiring and
connectors to the backplane. The ROC827 base unit supports up to three
I/O modules. Each expandable backplane (EXP) can accommodate up to
six I/O modules, and a fully configured ROC827 can handle up to 27 I/O
modules (three on the base unit and six modules on each of up to four
expandable backplanes). Each I/O module electrically connects to field
wiring by a removable terminal block. Refer to Figures 4-1 and 4-2.

Note

: Figure 4-2 represents a ROC827 with one EXP.
