ROC827 Instruction Manual

Issued Mar-06

Power Connections

3-16

Table 3-10. Power Consumption of the Discrete Output Relay Modules

Power Consumption (mW)

I/O Module

Description P

TYPICAL

Quantity

Used

Duty

Cycle

Sub-Total

(mW)

DOR Module

6.8 mA @ 12 volts dc

No Channels Active

81.6 mW

Channel 1

150 mA for 10 mSec

during transition

1800 mW

for 10 mSec

Channel 2

150 mA for 10 mSec

during transition

1800 mW

for 10 mSec

Channel 3

150 mA for 10 mSec

during transition

1800 mW

for 10 mSec

Channel 4

150 mA for 10 mSec

during transition

1800 mW

for 10 mSec

Channel 5

150 mA for 10 mSec

during transition

1800 mW

for 10 mSec

Per Active LED –
Maximum 5

1.5 mA

18 mW for

10 mSec

Table Total

Duty Cycle

The duty cycle is:

[((Number of Transitions in some time period) * 0.01 sec)] ÷ (Seconds in the period) = Duty Cycle

For example, if a DOR channel changes state 80 times per hour:

ƒ 80 = Number of transitions.
ƒ Hour is the time period.
ƒ An hour contains 3600 seconds.

Calculate the duty cycle as:

Duty Cycle = [(80 * 0.01) ч 3600] = 0.0002
