ROC827 Instruction Manual

Issued Mar-06

Installation and Use

2-15

Table 2-1. CPU Connector Locations

CPU Number

Definitions

J4 Not

Used

P2

LOI Port RJ-45

P3 Ethernet

RJ-45

P4

License Key Terminal

P6

License Key Terminal

SW1 LED

Button

SW2 RESET

Button


The CPU contains a microprocessor supervisory circuit. This device
monitors the battery voltage, resets the processor, and disables the SRAM
chip if the voltage goes out of tolerance. The CPU has an internal Analog
to Digital Converter (A/D). The A/D monitors the supply voltage and
board temperature (refer to “Automatic Self-Tests” in Chapter 1, General
Information).

The CPU has two buttons, LED and RESET (see Figures 2-6 or 2-7):

ƒ RESET: Use this button to reset the ROC827 to system defaults (refer

to “Preserving Configuration and Log Data” in Chapter 6,
Troubleshooting).

Note

: First, remove power from the ROC827. Then press and hold in

the RESET button while you re-apply power to the ROC827. Finally,
release the RESET button.

ƒ LED: Press to turn on the LEDs on the CPU module, I/O modules,

and communication modules when the ROC827 has timed out.

The STATUS LED helps to indicate the integrity of the ROC827 (refer to
Table 2-2).

Table 2-2. STATUS LED Functions

Status LED

Color

Definitions

Solution

Continually
Lit

Green

ƒ ROC827 functioning normally.

ƒ N/A

ƒ Low Battery Voltage alert.

ƒ Charge battery.

Continually
Lit

Red

ƒ System AI (Point number 1) LoLo

Alarm.

ƒ Apply DC voltage source.

Flashing Green

ƒ Firmware

invalid.

ƒ Update

firmware.

Flashing

Green-Green
to Red-Red

ƒ Firmware update in

decompression.

ƒ Do not restart the ROC827.

Flashing

Green to Red

ƒ Firmware update is flashing image. ƒ Do not restart the ROC827.

To save power, you can enable or disable the LEDs on the ROC827 (with
the exception of the LED on the power module). Using the ROCLINK 800
software, you can define how long the LEDs remains on after you press
the LED button on the CPU module. For instance, with the default setting
of five minutes, all LEDs turn off after five minutes. If you press the LED
