Edirol PC-80 - Manual (Page 36)

36
Playing the PC-80 keyboard
Use Upper mode to select the Upper sound.
■
Selecting the Upper sound from the PC-80
fig.upper
1
Press the PC-80’s UPPER button.
The PC-80’s UPPER button will light; Upper mode is selected.
The sound name field shows the name of the sound currently
selected for the Upper part.
2
Select the sound. ( ➔ “Selecting sounds” (p. 34))
■
Selecting the Upper sound from the Synth panel
1
In the Synth panel, click the UPPER button.
The Synth panel’s UPPER button will light; Upper mode is selected.
The sound name field shows the name of the sound currently selected for the
Upper part.
2
Select the sound. ( ➔ “Selecting sounds” (p. 34))
Play the keyboard, and you will hear the sound selected for Upper mode.
Selecting the Upper sound
C7 C7 C6 C6 C5 C5 C4 C4 C2 C3 C2 C2
C7 C7 C6 C6 C5 C5 C4 C4 C2 C3 C2 C2
Click
