SPI9000 Inverter Unit FI9 – FI14 User Manual
5-22 For more information visit: www.EatonElectrical.com MN04004002E
September 2006
Parameter Lock (P6.5.2)
This function allows the user to prohibit changes to the parameters.
If the parameter lock is activated, the text *locked* will appear on the display if you try to edit
a parameter value.
Note: This function does not prevent unauthorized editing of parameter values.
Enter the edit mode by pressing Menu Button Right. Use the Browser buttons to change the
parameter lock status. Confirm the change with the ENTER button or go back to the previous
level by pressing Menu Button Left.
Figure 5-17: Parameter Locking
Start-Up Wizard (P6.5.3)
The Start-Up Wizard facilitates the commissioning of the inverter. If active, the Start-Up
Wizard prompts the operator for the language and application of his/her choice and then
displays the first menu or page.
Activating the Start-Up Wizard: In the System Menu, find page P6.5.3. Press Menu Button
Right once to enter the edit mode. Use the Browser buttons to select Yes and confirm the
selection with the ENTER button. If you want to deactivate the function, follow the same
procedure and give the parameter value “NO”.
Figure 5-18: Activation of Start-Up Wizard
Parameter Lock
56.5.2
Security System Menu
M6
S1 S9 P1 P4 ChangeEnable
Parameter Lock
56.5.2
Parameter Lock
56.5.2
ChangeDisabl ChangeEnable
Confirm
Cancel
Startup wizard
P6.5.3
No
Startup wizard
P6.5.3
Startup wizard
P6.5.3
No Yes
