SPI9000 Inverter Unit FI9 – FI14 User Manual
MN04004002E For more information visit: www.EatonElectrical.com 3-13
September 2006
Inverter Supply and Motor Cables — 525 – 690V AC
Table 3-6: Cable Sizes for 525 – 690V AC
ᕃ Flexible conductor. Minimum temperature endurance for isolation 70°C.
ᕄ Copper busbar.
ᕅ The modules require symmetrical parallel cable with minimum length 40m or dU/dt- or sinus filter.
Table valid for enclosure class IP20 cabinets.
Motor cables — EN 60204-1, IEC 60364-5-2/2001
– PVC insulation
– 40°C ambient temperature
– 70°C surface temperature
Nominal
Current
Frame I
L
[A]
Module Supply (DC)
(per terminal Cu [mm
2 ]
Motor Cable
[mm
2 ]
100 FI9 125 2x(1x24) ᕃ Cu: 3x95+50
Al: 3x120+70
125 144 2x(1x24) ᕃ Cu: 3x95+50
Al: 3x120+70
144 170 2x(1x24) ᕃ Cu: 3x95+50
Al: 3x120+70
170 208 2x(1x24) ᕃ Cu: 3150+70
Al: 3x240Al+72Cu
208 FI10 261 3x(1x24) ᕄ Cu: 3x185+95
Al: 2x(3x95Al+29Cu)
261 325 5x40 ᕄ Cu: 2x(3x95+50)
Al: 2x(3x150Al+41Cu)
325 385 5x40 ᕄ Cu: 2x(3x120+70)
Al: 2x(3x185Al+57Cu)
325 416 5x40 ᕄ Cu: 2x(3x150+70)
Al: 2x(3x185Al+57Cu)
385 FI12 ᕅ 460 5x40 ᕄ Cu: 2x(3x150+70)
Al: 2x(3x240Al+72Cu)
460 502 5x40 ᕄ Cu: 2x(3x185+95)
Al: 2x(3x300Al+88 Cu)
502 590 5x40 ᕄ Cu: 2x(3x240+120)
Al: 4x(3x120Al+41Cu)
590 650 5x40 ᕄ Cu: 4x(3x95+50)
Al: 4x(3x150Al+41Cu)
650 750 5x40 ᕄ Cu: 4x(3x120+70)
Al: 4x(3x150Al+41Cu)
650 820 5x40 ᕄ Cu: 4x(3x150+70)
Al: 4x(3x185Al+57Cu)
820 FI13 920 5x40 ᕄ Cu:4x(3x150+70)
Al:4x(3x2405+72Cu)
920 1030 5x40 ᕄ Cu:4x(3x185+95)
Al:5x(3x185+57Cu)
1030 1180 5x40 ᕄ Cu:5x(3x185+95)
Al:6x(3x185+72Cu)
1300 FI14 ᕅ 1500 5x40 ᕄ Cu: 2x4x(3x120+70)
Al: 2x4x(3x150Al+41Cu)
1500 1900 5x40 ᕄ Cu: 2x4x(3x185+95)
Al: 2x5x(3x185+57Cu)
1900 2250 5x40 ᕄ Cu: 2x5x(3x185+95)
Al: 2x6x(3x185+72Cu)
