Extron • Matrix 200 • User’s Manual
Appendix B • Programming Guide
B-4
Simple Instruction List
The following table shows the simple command set with responses for the Matrix
200. The Response column shows what will be seen on the host’s screen.
Appropriate response messages are also displayed on the Matrix 200’s LCD
screen. The Hex column gives hexadecimal equivalents for cases where the
codes will be generated by another source.
All simple commands are preceded by ESC (1B hex). Version 1.8 of the Main
Controller software supports the Simple Instruction Set.
Switcher Commands ASCII Hex Matrix Response Result Description
Switcher Power On [ESC] < 3C
↵
SYS·1
↵
Turn System Power On
Switcher Power Off [ESC] > 3E
↵
SYS.0
↵
Turn System Power Off
Executive Mode On [ESC] X 58
↵
EXE·1
↵
Turn Executive Mode On
Executive Mode Off [ESC] x 78
↵
EXE·0
↵
Turn Executive Mode Off
Display Part Number [ESC] N/n 4E/6E
↵
N60-138-01
↵
Return part number
