B-5
CrossPoint 450 Plus and MAV Plus Switchers • Reference Information
General
Power (24- and 32-input models)
2 power supplies (1 primary, 1 redundant), 100 VAC to 240 VAC, 50/60 Hz,
internal
2412/2424 Series: 150 watts
3216/3232 Series: 180 watts
Power (all other models) ............ 100 VAC to 240 VAC, 50/60 Hz, internal
84/88/124/128 Series: 30 watts
816/1212/168/1616 Series: 36 watts
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Cooling
84-1616 Series ...................... Convection, unvented
2412-3232 Series .................. Forced air, right to left (as viewed from the front)
Rack mount ................................... Yes
Enclosure type .............................. Metal
Enclosure dimensions (Depth excludes connectors. Width excludes rack ears.)
84/88/124/128 Series .......... 5.25" H x 17.0" W x 9.4" D (3U high, full rack wide)
13.3 cm H x 43.2 cm W x 23.9 cm D
816/1212/168/1616 Series .. 10.5" H x 17.0" W x 9.7" D (6U high, full rack wide)
26.7 cm H x 43.2 cm W x 24.6 cm D
2412/3216 Series ................. 14.0" H x 17.0" W x 12.0" D (8U high, full rack wide)
(35.5 cm H x 43.2 cm W x 30.5 cm D)
2424/3232 Series ................. 17.5" H x 17.0" W x 12.0" D (10U high, full rack wide)
(44.5 cm H x 43.2 cm W x 30.5 cm D)
Product weight
84/88/124/128 Series .......... 14.4 lbs (6.5 kg)
816/1212/168/1616 Series .. 19.4 lbs (8.8 kg)
2412/3216 Series ................. 39.0 lbs (17.7 kg)
2424/3232 Series ................. 42.0 lbs (19.1 kg)
Shipping weight
84/88/124/128 Series .......... 21 lbs (10 kg)
816/1212/168/1616 Series . 26 lbs (12 kg)
2412/3216 Series ................. 56 lbs (26 kg)
2424/3232 Series ................. 60 lbs (28 kg)
DIM weight, international
84/88/124/128 Series ......... 25 lbs (12 kg)
816/1212/168/1616 Series . 34 lbs (15.5 kg)
2412/2424/3216/3232 Series
89 lbs (41 kg)
Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
All nominal levels are at ±10%.
Specifications are subject to change without notice.
