4-13 CrossPoint 450 Plus and MAV Plus Switchers • Programmer’s Guide
Command/response table for SIS commands (Cont’d)
Command ASCII Command Response Additional description
(host to switcher) (switcher to host)
Save, recall, and directly write presets (continued)
Read room outputs Esc X8 MR X19 , Y1 , Y2 , Yn
Example: Esc 3MR Class 1,01,02,08,09 Outputs 1, 2, 8, and 9 are
assigned to room 3, which is
named “Class 1”.
Recall a room preset X8 * X12
.
Rmm X8 •Rpr X12 Command character is a period.
Directly write a room preset Esc + X8 * X12 P X2 * X3 ! X2 * X3 % X2 * X3 $… X2 * X3 & Enter as many ties as are valid
Rmm X8 •Spr X12 for this model. Tie all (!), tie
RGBHV (&), tie video (%), and
tie audio ($) commands are all
valid.
Example: +7*3P12*7&13*35$4*26%6*6! Esc Brackets are shown to separate ties
Rmm07•Spr03 for clarity only. Create preset 3
for room 7, which ties audio
input 12 to output 7, video input
13 to output 35, RGBHV input 4
to output 26, and video and
audio input 6 to output 6.
Lock (executive) modes
See “Setting the front panel locks (Executive modes)” in chapter 3, “Operation” for more
information on the Lock modes.
Lock all front panel functions 1X Exe1 Enable Lock mode 1.
Lock advanced front panel functions 2X Exe2 Enable Lock mode 2.
Unlock all front panel functions 0X Exe0 Enable Lock mode 0.
View Lock mode X X9
Resets
Reset global presets and names Esc ZG Zpg Clear all global presets and their
names.
Reset an individual global preset Esc X11 ZG Zpg X11 Clear global preset X11 .
Reset RGB delays Esc ZD Zpd Reset all RGB delays to 0.0
seconds.
Reset audio input levels Esc ZA Zpa Reset all audio input levels (gain
and attenuation) to 0 dB.
Reset audio output levels Esc ZV Zpv Reset all audio output levels
(volume) to 100% (no attenuation).
Reset all mutes Esc ZZ Zpz Reset all video and audio mutes.
Reset room map Esc ZR Zpr Clear all room presets.
Reset individual room Esc X8 ZR Zpr X8 Clear all presets for room X8 .
Reset individual room preset Esc X8 * X12 ZP Zpp X8 * X12 Clear individual room preset and
name.
Reset flash Esc ZFFF Zpf Reset flash memory (erase user-
supplied files).
Reset whole switcher Esc ZXXX Zpx Clears all ties and presets, resets
all audio gains to 0 dB, and resets
volume to 100%.
Absolute reset Esc ZQQQ Zpq Similar to Reset whole switcher,
plus clears IP address to
192.168.254.254 and subnet mask
to 255.255.0.0.
