Programmer’s Guide, cont’d
CrossPoint 450 Plus and MAV Plus Switchers • Programmer’s Guide 4-16
Command/response table for SIS commands (Cont’d)
Command ASCII Command Response Additional description
(host to switcher) (switcher to host)
View ties, gain, volume, mutes, presets, and DSVP (continued)
View DSVP (sync frequency) X1 LS X15
,
X15
View connections 0LS X16
1
X16
2
•...• X2
n
Each X16 response is the
(CrossPoint 450 Plus only) connection status of an input,
starting from input 1, n is the
maximum number of inputs for
this model.
Information requests
Information request I V X2 X X3 •A X2 X X3 V X2 X X3 = V size, A X2 X X3 = A Size.
Example: I V32X16•A32X16 32 video and 32 audio inputs by
16 video and 16 audio outputs
(CrossPoint 450 Plus 3216 HVA).
Request part number N xx-xxx-xx See appendix B for part #s.
Example: N 60-468-01 CrossPoint 450 Plus 2424 HVA
part # is 60-468-01.
There are up to three separate sets of Extron firmware that the switcher can report on: the
CrossPoint/MAV Plus controller firmware, which is the overall control firmware; the Ethernet
protocol firmware, which handles the Ethernet interface; and the latest optional Extron firmware
update, which is available at www.Extron.com.
Query controller firmware version Q X17
Example: Q 1.23 The factory-installed
CrossPoint/MAV Plus controller
firmware version is 1.23
(sample value only).
Query software version (verbose) 0Q X17
-
X18
-
X18 Provide a detailed status of the
Ethernet protocol firmware, the
CrossPoint 450 Plus/MAV Plus
controller firmware, and any
firmware upgrade. The
firmware that is running is
marked by asterisk (*). A caret
(^) indicates that the firmware
has a bad checksum or an invalid
load. ?.?? indicates that firmware
is not loaded.
Response description: Ethernet protocol firmware version
-
controller firmware version
-
updated firmware version
Example: 0q
Ethernet protocol
firmware
Response:
Description
CrossPoint/MAV firmware version
1.23-0.14(0.20-32x32 Series - , 00 2000 00:00:00 GMT)-0.25*(0.24-32x32 Series -Thu, 20 Mar 2003 16:39:21 GMT)
Updated firmware version
* indicates the version running Upload date and time
Request system status S X20 • X20 • X20 • X20 • X20 • X20 • X20 • X21 • X22 • X22 • X9 • X9
Response description: +5V•+3.3V•+2.5V•Fan voltage•-5V•-12V•+12V•Temp•Fan1 RPM•Fan2 RPM•Primary PS•Secondary PS
Example:
S
4.98•3.30•2.55•11.52•-5.21•-12.35•11.65•78.80•753•774•1•1
Fans receiving 11.52 V Secondary power supply is on and Ok
Fan 1 rotating at 753 RPM 5V power system at 4.98V
