4-15 CrossPoint 450 Plus and MAV Plus Switchers • Programmer’s Guide
Command/response table for SIS commands (Cont’d)
Command ASCII Command Response Additional description
(host to switcher) (switcher to host)
View ties, gain, volume, mutes, presets, and DSVP (continued)
View audio global preset configuration Esc X11 * X3 *2VC X2
1 • X2
2 • X2
3 •...• X2
16 •Aud Show preset X11 ’s audio
configuration. Show the audio
input tied to 16 sequential
outputs, starting from output
X3 .
Command description: preset#*starting output# (StO#)*2(=audio)VC
Response description: input # (I#) assigned to StO#•I# assigned to StO#+1...I# assigned to StO#+15•Aud
Example (CrossPoint 450 Plus 2412): Esc 0*1*2VC
01 Output:
Response = tied input:
input 1 tied to output 3
02 03 04 05 06 07 08 09 10 11 12
01•01•01•01•02•22•22•00•03•03•03•03•--•--•--•--•Aud
13 14 15 16
no tied input no outputs
The starting output # (StO#) should always be 1 for matrix sizes of 16 outputs or smaller.
Esc X11
*
X3
*2VC where
X11
= 0 returns the switcher’s current audio configuration.
Audio — Input 1 is tied to outputs 1 through 4, input 2 is tied to output 5, input 3 is tied to outputs 9 through 12, and
input 22 is tied to outputs 6 and 7. No input is tied to output 8. The switcher in this example is a
CrossPoint 450 Plus 2412, so outputs 13 through 16 are not present.
View video room preset configuration Esc X8 * X12 *1*1VC X2 • X2
1 • X2
2 •...• X2
15 •Vid Show room X8 , preset X11 ’s
video configuration. Show the
video input tied to up to 16
outputs, assigned to room
X8 .
Command description: room#* room preset#*starting output# (StO#) (always 1)*1(=video)VC
Response description: input # (I#) assigned to StO#•I# assigned to StO#+1...I# assigned to StO#+15•Vid
The starting output # (StO#) should always be 1 for matrix sizes of 16 outputs or smaller.
View audio room preset configuration Esc X8 * X12 *1*2VC X2 • X2
1 •...• X2
15 •Aud Show room X8 , preset X11 ’s
audio configuration. Show the
audio input tied to up to 16
outputs, assigned to room
X8 .
Command description: room#* room preset#*starting output# (StO#) (always 1)*2(=audio)VC
Response description: input # (I#) assigned to StO#•I# assigned to StO#+1...I# assigned to StO#+15•Aud
The starting output # (StO#) should always be 1 for matrix sizes of 16 outputs or smaller.
The response to the View File Directory command differs, depending on whether the command
is sent via a serial port or Telnet connection or sent via a Web browser connection.
View file directory serial port and Esc DF filename1,date/time,length List user-supplied files.
Telnet filename2,date/time,length
filename3,date/time,length
• •
• •
filenamen,date/time,length
space_remaining Bytes•Left
View file directory Web browser Esc DF Var file = new array (); List user-supplied files.
File [1] = ‘filename1,date1,filesize1’;
File [2] = ‘filename2,date2,filesize2’;
File [3] = ‘filename3,date3,filesize3’;
• •
• •
File[n] = ‘filenamen,daten,filesizen’;
File[n+1] = space_remaining Bytes•Left
Erase user-supplied Web pages/files Esc filenameEF Delfilename
