Maintaining and Transporting the Printer
|
121
3. Select the
Nozzle Check
icon and follow the instructions on the screen.
4. After the pattern is printed, use at least a 10
×
eye loupe to examine it.
•
If the pattern looks good, as shown below, the print head is clean.
•
If any dots or segments are missing or deflected, as shown below,
run a cleaning cycle as described on page 124. Then print another
nozzle check pattern to make sure the nozzles are clean.
•
If the nozzles are still clogged after three cleaning cycles, run a power
cleaning cycle as described on page 124.
Windows
Mac OS X
Caution: Don’t run a
cleaning cycle while
thick media is loaded in
the printer.
