Retrofit Installation
47
Figure 20 STS2 NIC installation, 100 - 600A units
9.12 STS
Retrofit kits are designed specifically for individual units. Consult
your local sales / service representative for pricing, part numbers and
installation help.
STS units require the use of an external enclosure. Consult the corre-
sponding section of this manual regarding installation details.
9.13 PDU and DataWave with PMP & EPMP
Retrofit Kits are designed specifically for individual units. Consult
your local sales / service representative for pricing, part numbers and
installation help.
All compatible PDU’s and DataWave’s require the use of an external
enclosure. Consult the corresponding section of this manual regarding
installation details.
Front View With Front Door Removed
CONTROL WIRING
COMMS BOARD FOR SITESCAN,
INPUT CONTACT ISOLATOR
PROGRAMMABLE RELAY
See
Option
Location
Detail
Option
Location
Detail
BOARD (OPTION)
BOARD (OPTION)
EXTERNAL AND INTERNAL
CARD (NIC) (OPTION)
NETWORK INTERFACE
MODEM INTERFACE (OPTION)
REMOTE SOURCE
SELECT (OPTION)
BOARD (OPTION)
PROGRAMMABLE RELAY
