Yaskawa YASNAC PC NC Maintenance Manual User Manual
Page 5
PC NC Maintenance Manual
Chapter 1: General Installation and Electrical Connection
1-2
Figure 1.2: The YASNAC PC NC System Structure Diagram
Feeding
servo unit
Spindle
drive unit
High voltage
I/O Module
Device
on
Spindle motor
Feeding
motor
Machine
Keyboard
Monitor with Touch screen
PC NC case
PC
ISA bus
DC
Mouse
machine side
+24V
power
JFC10
FDD
