The VS-626M5 PC NC Maintenance Manual
4-123
Note: A terminal arrangement is seen when the connectors on the PC board are viewed from the engaged
part (front of the unit).
1CN 6CN
36 MNTR2 18 0V 50 LM 25 0VCOM
35 MNTR1 17 SS 49 0V 24 0VCOM
34 VCC 16 *PBO 48 0V 23 24VCOM
33 0VCOM 15 PBO 47 SM 22 24VCOM
32 24VCOM 14 *PAO 46 SM 21 24VCOM0
31 EXTCOM 13 PAO 45 FLTCOM 20 EXTCOM0
30 D12 12 *PCO 44 FLTNC 19 COM
29 D11 11 PCO 43 FLTNO 18 MGR
28 D10 10 BAT+ 42 COM1 17 LGR
27 D9 9 BAT- 41 FLTL 16 ORT
26 D8 8 ALMC 40 CHWE 15 PPI
25 D7 7 ALM- 39 ORE 14 CHW
24 D6 6 ALM+ 38 ORG 13 RST
23 D5 5 ESP1 37 TLE 12 SSC(SV)
22 D4 4 ESP0 36 TDET 11 TLL(INC)
21 D3 3 /EXT2 35 SDET 10 TLH
20 D2 2 /EXT1 34 AGR 9 REV
19 D1 1 24VIN 33 ZSPD 8 FWD
2CN
32 — 7 EMG
31 — 6 RDY
20 — 10 +24V 30 COM2 5 DAS
19 *PB 9 THSB 29 FC3 4 0V
18 PB 8 THSA 28 FC2 3 SCOM
17 *PA 7 SS 27 FC1 2 SS
16 PA 6 +5V 26 FC0 1 +15V
15 PC 5 +5V
14 PC 4 +5V
13 CA2 3 0V
12 CA1 2 0V
11 CC 1 0V
3CN (Option)
14 — 7 +5V
13 — 6 OP1
12 — 5 0V
11 +5V 4 RX
10 — 3 0V
9 +5V 2 TX
8 OP2 1 0V
