PC NC Maintenance Manual The VS-626M5
4-86
4.3 Receiving
The following information describes how to verify the inverter after delivery to the
user.
Inspection Checkpoints
If any of the above checkpoints are not satisfactory, contact your Yaskawa
customer service representative.
Check the nameplate data as follows below.
(a) Nameplate Data
Example of model of 200VAC, 10HP (7.5kW)
• Do not install or operate any inverter or converter which is damaged or has missing
parts. Failure to observe this caution may result in personal injury or equipment dam-
age.
Checkpoints Description
Does the inverter model number cor-
respond with the purchase order? Open the upper cover of the VS-626M5 and check
the model number on the nameplate.
Are any parts damaged? Visually check the exterior and verify that there
was no damage during transport.
Is hardware properly seated and
securely tightened? Remove converter upper and lower covers.
Check all visible hardware with appropriate tools.
CAUTION
Serial No.
Inverter Model
Input Spec.
Inverter Spec.
Output Spec.
Mass
SPEC : 27P55E
YASKAWA ELECTRIC CORPORATION
INPUT : DC 270 - 325 V 9.3kW
MODEL : CIMR - M5A27P5
OUTPUT : AC 3PH 0 - 230 V 8.8kVA
SER NO : NW5A220-021-5 MASS: 5 kg
JAPAN
PRG : 0040 PROM No.
