The VS-626M5 PC NC Maintenance Manual
4-117
2CN +5V 4, 5, 6 +5V power supply for encoder +5V
Load current: 300mA or
less
0V 1, 2, 3 Encoder power supply common
PA 16 Encoder phase A signal input RS-422A specification
Line receiver
*PA 17
PB 18 Encoder phase B signal input
*PB 19
PC 14 Encoder phase C signal input
*PC 15
THSA 8 Motor thermistor signal _|
THSB 9
SS 7 Shielded wire connection (0V) _|
+24V 10 +24V power supply for winding selection
device +24V
CC 11 Winding selection device power supply
common
CA1 12 Winding status signal +24V
Load current: 10mA or less
CA2 13
Table 4.27: Control Circuit Signals (1, 2CN) (Continued)
