9 Main Command
YASKAWA ELECTRIC SIEP C730600 62B 1000-Series Option SI-ET3 Technical Manual 37
„ INV_CTL Response
6 DC Bus Voltage Displayed in U1-07 (1 V).
7 Inverter Alarm –
8 Inverter Warning –
9 Multi-Function Output Terminal Status Displayed in U1-11.
A Analog Input Terminal Displayed in U1-15 (0.1%).
B
Multi-Function Input Terminal Status
S1 to S8
Displayed in U1-10.
C Analog Input Terminal Displayed in U1-13 (0.1%).
D Speed Detection PG2 Counter –
E Monitor Data Set to F6-23 –
F Monitor Data Set to F6-24 –
INV_CTL Response
Byte Response Contents
0 INV_CTL (50H) Command code
1 RWDT Watchdog data
2
CMD_STAT Refer to Command Status (CMD_STAT) on page 24 .
3
4
INVCMD_STAT Refer to INVCMD_CTRL on page 35 .
5
6
7
8
INVCMD_IO Refer to INVCMD_IO Command on page 36 .
9
10
11
12
Output Frequency
Output Frequency (Lower)
13 Output Frequency (Upper)
14 Not used (Set to 0.)
15 Not used (Set to 0.)
16
Output Current
Output current (Lower)
17 Output current (Upper)
18 Not used (Set to 0.)
19 Not used (Set to 0.)
20 SEL_REF1/2 The value set in the command.
21 SEL_MON1/2 The value set in the command.
22
Reserved (0) Not used (Set to 0.)
23
24
Monitor data set to
SEL_MON1
Monitor data set to SEL_MON1 (Lower)
25 Monitor data set to SEL_MON1 (Upper)
26 Not used (Set to 0.)
27 Not used (Set to 0.)
28
Monitor data set to
SEL_MON2
Monitor data set to SEL_MON2 (Upper)
29 Monitor data set to SEL_MON2 (Upper)
30 Not used (Set to 0.)
31 Not used (Set to 0.)
Selection Code Monitor Name Contents
