SMA Solar Technology AG Technical Data
Installation Manual SMC46-60A11-IA-en-81 71
AC Output
* 4,600 VA with VDE-AR-N-4105
** Applies to SMC 4600A-11
*** Applies to SMC 4600A
Efficiency
Rated power at 230 V, 50 Hz 4,600 W
Maximum apparent AC power* 5,000 VA
Rated grid voltage 230 V
AC nominal voltage 220 V / 230 V / 240 V
AC voltage range 160 V ... 265 V
Nominal AC current at 220 V 20.9 A
Nominal AC current at 230 V 20.0 A
Nominal AC current at 240 V 19.16 A
Maximum output current 26 A
Total harmonic factor of the output current with
AC voltage < 2% and
AC power > 50% of the rated power ≤ 3%
Rated mains frequency 50 Hz
AC mains frequency 50 Hz/60 Hz
Operating range at AC mains frequency of
50 Hz 44 Hz … 55 Hz
Operating range at AC mains frequency of
60 Hz 54 Hz … 65 Hz
Displacement power factor, adjustable** 0.8
overexcited
… 0.8
underexcited
Power factor at nominal AC power*** 1
Feed-in phases 1
Connection phases 1
Overvoltage category according to
IEC 60664-1 III
Maximum efficiency, η
max
96.1%
European weighted efficiency, η
EU
95.3%
