HEIDENHAIN TNC 620 511
13.3 T
e
c
hnical Inf
o
rm
ation
Data interfaces „ One each RS-232-C /V.24 max. 115 kilobaud
„ Expanded data interface with LSV-2 protocol for remote operation of the TNC through
the data interface with the HEIDENHAIN software TNCremo
„ Ethernet interface 100BaseT
approx. 2 to 5 megabaud (depending on file type and network load)
„ 2 x USB 1.1
Ambient temperature „ Operation: 0°C to +45°C
„ Storage: –30 °C to +70 °C
Accessories
Electronic handwheels „ One HR 410 portable handwheel or
„ One HR 130 panel-mounted handwheel or
„ Up to three HR 150 panel-mounted handwheels via HRA 110 handwheel adapter
Touch probes „ TS 220: 3-D touch trigger probe with cable connection, or
„ TS 440: 3-D touch trigger probe with infrared transmission
„ TS 444: Battery-free 3-D touch trigger probe with infrared transmission
„ TS 640: 3-D touch trigger probe with infrared transmission
„ TS 740: High-precision 3-D touch trigger probe with infrared transmission
„ TT 140: 3-D touch trigger probe for workpiece measurement
Software option 1 (option number #08)
Rotary table machining ‹ Programming of cylindrical contours as if in two axes
‹ Feed rate in mm/min
Coordinate transformation ‹ Tilting the working plane
Interpolation ‹ Circle in 3 axes with tilted working plane
Software option 2 (option number #09)
3-D machining ‹ Motion control with very little jerk (HSC filter)
‹ 3-D tool compensation through surface normal vectors (only iTNC 530)
‹ Keeping the tool normal to the contour
‹ Tool radius compensation normal to the tool direction
Interpolation ‹ Linear in 5 axes (subject to export permit)
Block processing time ‹ 1.5 ms
Specifications
