324
8.5 SL Cy
cles
20 LBL 1 Contour subprogram 1: left pocket
21 CC X+35 Y+50
22 L X+10 Y+50 RR
23 C X+10 DR-
24 LBL 0
25 LBL 2 Contour subprogram 2: right pocket
26 CC X+65 Y+50
27 L X+90 Y+50 RR
28 C X+90 DR-
29 LBL 0
30 LBL 3 Contour subprogram 3: square left island
31 L X+27 Y+50 RL
32 L Y+58
33 L X+43
34 L Y+42
35 L X+27
36 LBL 0
37 LBL 4 Contour subprogram 4: triangular right island
38 L X+65 Y+42 RL
39 L X+57
40 L X+65 Y+58
41 L X+73 Y+42
42 LBL 0
43 END PGM C21 MM
