NV8288 and NV8288-Plus Digital Video Routers • User’s Guide 65
7. Technical Details
Physical Specifications
Modules and slots NV8288
24 Input cards, 12 signals each,
48 Output cards, 12 signals each,
2 Crosspoint cards,
2 Control cards (1 primary, 1 optional secondary),
1 Monitor card set,
2 Fan modules
NV8288-Plus
24 Input cards, 12 signals each,
48 Output cards, 6 output signals plus 6 expansion signals,
48 Output filler cards, 6 expansion signals,
2 Crosspoint cards,
2 Control cards (1 primary, 1 optional secondary),
1 Monitor card set,
2 Fan modules
Diagnostic Type: serial port, 38.4 baud, 8-N-1.
Standard: SMPTE 207M, EIA-232, non-configurable.
Connector: 2, DE9.
Serial control Type: Serial port (2 per control card).
Standard: SMPTE 207M, EIA-422.
Connectors: 4, DE9.
Ethernet Type: 10/100baseT.
Standard: IEEE 802.3.
Protocol: Miranda Ethernet protocol.
Connectors: 2, RJ45.
Output signal monitor Type: standard definition and high definition digital video.
Standard: see related section of this specification for standard for each
monitored signal type.
Connector: DIN 1.0/2.3.
Impedance: 75
Ω.
Signal details: See related section of this specification for details for each
monitored signal type, including jitter, I/O levels and return loss.
I/O expansion NV8288-Plus
Type: proprietary.
Standard: see related section of this specification for standard for each signal
type sent between routers.
Connectors: 48, proprietary, Miranda cable
WC0089-00.
Signal details: See related section of this specification for details for each
signal type, I/O levels and return loss.
Control expansion NV8288-Plus
Type: 10/100baseT.
Standard: IEEE 802.3.
Connectors: 2, RJ45.
Power supply monitor Connector: DB25.
Parameter Detail
