NV8288 and NV8288-Plus Digital Video Routers • User’s Guide 51
3. Installation
Verification
The following table lists each DE9 pin and the associated alarm. The pin number listed corresponds
to the pin numbers in Figure 3-25 on page 50:
Verification
When installation is complete, perform the following checks to make sure the router is operating
properly:
• On the NV6257 power supply or the NCV8000 power supply, check that all 5 green power
LEDs on the front of each power supply module are lit. If any or all LEDs are off:
Check that the power supply module is fully seated in its slot.
Check the AC fuse on the PS6000 or the PS8010 power supply modules.
Check for +48 volts at each of the 5 front test points.
• On the NV8288 or the NV8288-Plus, check that the LEDs on the input cards, crosspoint cards,
control cards, and output cards are lit and indicating a “healthy” system. See Indicator LEDs on
page 58 for a list of normal and alert LED states.
• Make sure that the flow of air through the front of the router is unimpeded and the door is prop-
erly installed and closed. For more information, see Air Flow on page 59.
Pin Signal Description Possible Conditions Causing the Alarm
1 and 9 Alarm_COM Common Common connection for all alarm pins.
2 Alarm_1 Major alarm Indicates missing reference inputs, or missing power
supplies.
3 Alarm_2 Minor alarm Alarm_3, or Alarm_4, or Alarm_5, or Alarm_6
4 Alarm_3 Power supply Missing power supply module.
5 Alarm_4 Video reference Missing video reference 1 or video reference 2.
6 Alarm_5 AES3 reference Not used in the NV8288.
7 Alarm_6 Fans or temperature Indicates a fan failure or module over temperature.
8 Alarm_7 Control module
health
Any control module not “healthy.”
