11 DV audio encode
Lets you select any of the following settings below related to the
DV audio format used for DV encoding.
LCD Display
Setting Description
48kHz CH1/2 48 kHz/2 channels; encode CH1 and CH2
audio inputs.
(Factory default)
32kHz CH1234 32 kHz/4 channels; encode CH1, CH2, CH3
and CH4 audio inputs.
48kHz CH3/4 48 kHz/2 channels; encode CH3 and CH4
audio inputs as CH1 and CH2 for DV.
12 digital audio in
Lets you select any of the following settings related to the
digital audio input in SDI J DV mode (during DV encoding).
LCD Display
Setting Description
Embedded Selects SDI embedded audio.
(Factory default)
AES/EBU Selects AES/EBU audio.
13 digital audio out
Lets you select any of the following settings related to the
digital audio output.
LCD Display
Setting Description
through out Outputs each input source audio directly.
(Factory default)
selected audio Outputs audio selected for “12 digital audio
in” menu item.
Info
When the DV audio encoding
setting is 32 kHz, the "selected
audio" setting has no effect.
Change the setting to "through
out", or change the DV audio
encoding setting of menu item 11
("DV audio encode") to 48 kHz.
DV audio input is output in DV J
SDI mode (during DV decoding).
