78 8985FSP/FS — Instruction Manual
Configuration Parameter Summary
Recall factory default signal names N/A
See 8985FSP I/O Config Web
Page on page 40 .
User Settings/
Recall Factory Names
Set Factory Names button
N/A
Genlock enable control Enable Enable or Freerun
Genlock/
Genlock Control
Enable or Freerun radio button
GLEnable
Genlock input standard
selection
1080i 59.94
NTSC,
PAL,
1080i 59.94
720p 59.94
1080i 50
720p 50
1080p 24,
1080sF 24,
AES 46K,
AES 96K,
Word Clock 46K,
or Word Clock 96K
Genlock/
Genlock Control
Input Standard Selection
pulldown
GLInSel
Set loop bandwidth Low Jitter Low Jitter or Fast Lock
Genlock/
Genlock Control
Loop Bandwidth radio button
GLLoopBW
Set line offset
(SD standard settings)
0 lines
NTSC: 0 to 524 lines
PAL: 0 to 624 lines
1080i 59.94: 0 to 524 lines
720p 59.94: 0 to 524 lines
1080i 50: 0 to 624 lines
720p 50: 0 to 624 lines
1080p 24: 0 to 624 lines
1080sf 24: 0 to 624 lines
AES 48K: 0 to 624 lines
AES 96K: 0 to 624 lines
Word Clock 48K: 0 to 624 lines
Word Clock 96K: 0 to 624 lines
Genlock/
Genlock Bus Timing
Line Offset control
GLLineOff
Set coarse offset 0
NTSC: 0 to 1715
PAL: 0 to 1727
1080i 59.94: 0 to 1715
720p 59.94: 0 to 1715
1080i 50: 0 to 1727
720p 50: 0 to 1727
1080p 24: 0 to 1727
1080sf 24: 0 to 1727
AES 48K: 0 to1727
AES 96K: 0 to 1727
Word Clock 48K: 0 to 1727
Word Clock 96K: 0 to 1727
Genlock/
Genlock Bus Timing
Coarse Offset control (37 ns)
GLcors
Set fine offset 0 All Formats: 0 to 255
Genlock/
Genlock Bus Timing
Fine Offset control
GLfine
Set reference source to drive frame
bus
Off Off or Auto
Genlock/
Drive Frame Reference Bus:
pulldown
GLBusDrv
Enable Fiber TX1 output
(Dual Transmiller fiber optic submod-
ule installed.
Not Enabled Enabled or Not Enabled
Video Output/
Fiber TX1 Enabled Checkbox
N/A
Enable Fiber TX2 output
(Dual Transmitter or Transceiver fiber
optic submodule installed.
Not Enabled Enabled or Not Enabled
Video Output/
Fiber TX2 Enabled Checkbox
N/A
Table 9. Summary of 8985FSP/FS Configuration Functions
Function
Type
Default
Range/Choices
Resolution
Web Page/
Function Name
Newton
Control
Panel
