LDK 4410 + LDK 5420 3G Fiber Transmission System User’s Guide (v1.0) 51
Chapter 5 - Menus
5.1.5 SDTV menu
☞
Note
☞
Note
This menu is only available when the optional LDK 4531/30 High Quality SD board is installed.
Menu item Values Description Level File
Contour
Contour On, Off Turns contour on or off. Oper Scene
Source G, R, Y, R+G Selects the source to be used for contour
generation. Oper Scene
Level 0..99 (10) Sets contour level. Oper Scene
Vertical Level 0..99 (50) Sets the level of the vertical component in
the contour signal. Oper Scene
Noise Slicer 0..99 (6) Sets the level of the noise slicer. Oper Scene
Coarse/fine 0..99 (25) Sets the coarseness of the contour (0 =
very fine) Oper Scene
Level Dependence 0..99 (25) Sets the dependency level for the noise
slicer. Oper Scene
Soft Contour On, Off Turns soft contour on or off. This function
reduces the amount of contour added for
large transitions. Oper Scene
Soft Contour Level 0..99 (70) Sets the upper limit level for soft contour. Oper Scene
Video Output GRB, YPrPb, CVBS, Off Select signal type for the SD video outputs. Install Scene
Aspect Ratio 16:9, 4:3 Selects aspect ratio for SD signal. Install
Letterbox Off, 16:9 Selects letterbox function (only when
aspect ratio = 4:3) Install
