LDK 4410 + LDK 5420 3G Fiber Transmission System User’s Guide (v1.0)
Chapter 4 - Transmission
1.
Insert a very small screwdriver into the hole at the left side and then at the right side of
the fuseholder to unclip both side of the fuseholder.
2.
Extract the fuseholder from the mains entry by pulling of the small clip at the bottom of
the fuseholder.
3.
Replace both fuses.
4.
Insert the fuseholder until it clicks into place.
5.
Connect the power supply for the base station to the IEC connector at the rear.
Insert small
screwdriver here
to open clip
Insert small
screwdriver here
to open clip
