2031RDA-SM/-MM Instruction Manual 13
Configuration and Monitoring
Configuration and Monitoring
The 2031RDA-SM/-MM can be configured locally using on-board switches
or remotely using the 2000NET network interface GUI or a Newton Control
Panel. Operation of these control types is explained in detail in their respec-
tive sections of this manual.
Note Not all available functions are configurable with the local on-board controls.
Refer to the following sections for configuration instructions:
• Configuration Summary ( page 13 )
• Local On-board Configuration ( page 14 )
• Remote Configuration and Monitoring ( page 16 )
Configuration Summary
The configuration parameters and monitoring functions available with the
local on-board jumpers, web browser interface, and the Newton Control
Panel are summarized in
Table 3 . The parameter defaults, choices, ranges,
and resolution are provided for each function.
Table 3. Summary of 2031RDA-SM/-MM Configuration Functions
Function
Type
Default
Range/Choices
Resolution
Web Page/
Function Name
On-Board Jumper
Setting
Newton
Control
Panel 1
1 Newton Control Panel operation for this module requires a 2000NET module running version 4.0.0 or later in the frame.
Input
Reverts to on-board
jumper settings
Coax or Fiber
Settings/
Input pulldown
J112 pins 1-2 = Electrical Input
J112 pins 2-3 = Fiber Input
InpSel
Mode
Bypass
Auto
Auto Reclock
Manual 143M
Manual 177M
Manual 270M
Manual 360M
Manual 540M Settings/
Mode Pulldown
J106 pins 1-2 = AUTO
J106 pin 2 only =270 Mb
J106 pins 2-3 = BYPASS
Mode
Optic Tx Enabled or Disabled
Settings/
Optic TX pulldown
J110 pins 1-2 = Fiber Tx En
J110 pins 2-3 = Fiber Tx Dis
OpticTx
Recall factory
defaults
– See Default column
Recall Factory Defaults
Recall Factory
Defaults button
N/A N/A
