4
Appendix
50
Specifications
■
General
Receiving range E : 0.1 - 1299.995 MHz
T : 0.1 - 1299.995 MHz
Modulation modes : A3 (AM), F3 (FM, WFM)
Ant. impedance : 50
Ω
Ant. terminal : SMA
Supply voltage : DC 3.6V - DC 6V
(external input voltage DC 4.5V - DC 16V)
Ground : Negative ground
Current consumption : Reception : approx. 75 mA
Battery save (1 : 4) : approx. 39 mA
Temperature range : –10 ~ +60°C (+14 ~ +140°F)
Frequency stability : ±5 ppm (–10 ~ +60°C / +14 ~ +140°F)
Dimensions : W:56 H:102 D:23 mm (without projections)
(W:2.20 H:4.01 D:0.90 in.)
Weight : Approx. 145 g
(a NiMH battery pack and an antenna inclusive)
(Approx. 5 oz.)
■
Receiver
System : Triple-conversion superheterodyne
1st I.F : 248.45 MHz
2nd I.F. : 38.85 MHz
3rd I.F. : 450 kHz
Selectivity AM/FM : –6 dB/12 kHz or over, –60 dB/30 kHz or less
WFM : –6 dB/150 kHz or over
Sensitivity AM : 0.5 - 1.62 MHz 17dBµ or less 10dB S/N
(Typical) 1.62 MHz or over 5dBµ or less 10dB S/N
FM : 30 - 550 MHz -3dBµ or less 12dB SINAD
550 MHz or over 0dBµ or less 12dB SINAD
WFM : 13dBµ or less 12dB SINAD
Sub-freq. output : MAX 220mW or over (8
Ω
)
