5-104
18. KEYENCE PLC
KZ/KV Series CPU / KV-700 CPU
Communication parameters for the V7 series are automatically set.
KZ24/300 CPU
*1 Maximum baud rate available is 38400 bps. If a higher baud rate is selected, communications
are performed at 9600 bps.
KV10/24 CPU
*1 Maximum baud rate available is 57600 bps. If a higher baud rate is selected, communications
are performed at 9600 bps.
Available Memory
The available memory setting range varies depending on the PLC model. Be sure to set within the
range available with the PLC to be used. Use [TYPE] when assigning the indirect memory for macro
programs.
KZ Series Link
Item
Setting on PLC
V7 Comm. Parameter Setting
Port
0
0
Baud rate
38400 bps
38400 bps
*1
Parity
Even
−
Transmission code
Data length
8
−
Stop bit
1
−
Terminating resistance
−
−
Item
Setting on PLC
V7 Comm. Parameter Setting
Port
0
0
Baud rate
57600 bps
57600 bps
*1
Parity
Even
−
Transmission code
Data length
8
−
Stop bit
1
−
Terminating resistance
−
−
Memory
TYPE
Remarks
DM
(data memory)
0
CH
(input/output relay)
1
