4.6 Q-Series Modules
’ Audio Specifications
Audio Sampling Rate 46.875 kHz
Transmitter
Line Input Impedance: 10K Ω
Maximum Line Input: 2.5 volts peak to peak
Microphone Output Impedance: 300 Ω
Maximum Microphone Output: 0.45 volts peak to peak
Receiver
Line Output Impedance: 560 Ω
Maximum Output: 3 volts peak to peak
Microphone Input Impedance: 5K Ω
Maximum Microphone Input: 0.24 volts peak to peak
4.7 Q-Series Video Modules
’ Technical Specifications
Module Specifications Power Consumption: 10 watts per unit
VQM-3, VQM-3A,
VQM-3N, VQM-3R, VQM-
3H, VQM-3AH, VQM-3AVS,
VQM-3NH, VQM-3V, VQM-
3HV, VQM-AHV,
VQM-6, VQM-10AV+
Dimensions:
Height:
1.592” (40.43 mm)
Depth: 6.366" (161.69 mm)
Width: 3.693" (93.80 mm)
(Tolerance: ± .039"; 1 mm)
VQM-3 AV+
VQM-3AN+
VQM-6 AV+
VQM-6AN+
Dimensions:
Height:
1.592” (40.43 mm)
Depth:
6.366” (161.69 mm)
Width: 7.406" (188.11 mm)
(Tolerance: ± .039"; 1 mm)
Electrical Cables
(supplied with transmitters)
KIT-000005-R Audio Kit 1 (contains the following):
CBL000006-006FR 6 Pin Mini-DIN, Male to Male Cable, 6FT (2)
CBL000015-006FR USB A-B Cable, 6FT (2)
CBL000016-006FR 3.5mm Male to 3.5mm Male Plug, 6FT (2)
CBL000017-006FR DB9M to DB9F Cable, 6FT (1)
CBL000018-006FR BNC Male to BNC Male Cable
, 50Ω, 6FT (1)
DB9 to RJ45 Adapters
With AV+ models only:
ADP-000019-R DB9M to RJ45
ADP-000025-R DB9F to RJ45
Copper Video Cables
CBL000009-002MR Single-link DVI-D Male to Male, 2
meters
1 each, VQM-3, VQM-3 AV+, VQM-3 AN+
2 each, VQM-3V, VQM-3V AV+, VQM-3V AN+
CBL000013-002MR DVI-I Male to DVI-I Male, 2 meters
1 each, VQM-10AV+
CBL000022-002MR DVI Male to VGA Male, 2 meters
1 each, VQM-10AV+
CBL000023-002MR Dual-link DVI-D Male to Male, 2 meters
1 each, VQM-6, VQM-6 AV+, VQM-6 AN+
