TASCAM DR-60DMKII
25
Specifications
Ratings
Recording media
SD card (64MB – 2GB)
SDHC card (4GB – 32GB)
File system
WAV: 44.1/48/96 kHz, 16/24-bit
BWF (Broadcast Wave Format): 44.1/48/96 kHz, 16/24-bit
Number of channels
4 channels (stereo × 2)
Inputs and outputs
1/L connector, 2/R connector (phantom power supported)
Connector: XLR-3-31, 6.3mm (1/4”) standard TRS Jack
3-4 jack (supports plug-in power)
Connector: 3.5mm (1/8”) stereo mini jack
CAMERA IN jack
Connector: 3.5mm (1/8”) stereo mini jack
CAMERA OUT (LOW) jack
Connector: 3.5mm (1/8”) stereo mini jack
PHONES jack
Connector: 3.5mm (1/8”) stereo mini jack
CAMERA OUT (HIGH)/LINE OUT jack
Connector: 3.5mm (1/8”) stereo mini jack
USB jack
Connector: USB Mini-B Type
Format: USB 2.0 HIGH SPEED mass storage class
REMOTE jack
Connector: 2.5mm TRS Jack
Audio performance
Frequency response
20-20kHz +0.5/−2dB (LINE IN or MIC IN to LINE OUT, Fs44.1k/48kHz, JEITA)
20-40kHz +0.5/−3dB (LINE IN or MIC IN to LINE OUT, Fs96kHz, JEITA)
Distortion
0.02% or less (LINE IN or MIC IN to LINE OUT, Fs44.1k/48k/96kHz, JEITA)
S/N ratio
92dB or more (LINE IN or MIC IN to LINE OUT, Fs44.1k/48k/96kHz, JEITA)
Equivalent input noise
–120dBu or more Note) JEITA: Conforming to JEITA CP-2150
Recording times
File format (recording setting)
SD/SDHC card capacity
4 GB
WAV/BWF 16bit (STEREO) 44.1kHz 6:44:00
WAV/BWF 24bit (STEREO) 96kHz 2:04:00
•
The recording times shown above are estimates. They might differ depending
on the SD/SDHC card in use.
•
The recording times shown above are not continuous recording times, but
rather they are the total possible recording times for the SD/SDHC card.
•
If recorded in mono in WAV files, the maximum recording time will be double
the figures above.
•
For dual and 4-channel recording in WAV/BWF format, the recording times are
about half those shown above.
