TASCAM DR-60DMKII
13
Basic operation procedures
1. Press the MENU button to open the MENU
Screen.
2. Turn the DATA dial to select a menu item
(highlighted), and press the DATA dial or /
button to move to various settings screens.
3. Turn the DATA dial to select a menu item
(highlighted) to be set.
4. Press the DATA dial or / button to move
the cursor to highlight the value of the setting.
5. Turn the DATA dial to change the setting.
6. Press the DATA dial or . button to set a
different item in the same menu.
This enables you to select a new item. Turn the
DATA dial again to select an item to be set.
7. Repeat step 3 to 6 as necessary to set each
item.
8. To open the MENU screen (or OTHERS submenu
screen), press the MENU button. To return to
the Home Screen, press the stop (8) [HOME]
button.
Menu structure
MENU
REC MODE Make recording settings
INPUT SETTING Make input settings
REC SETTING Make recording settings
AUTO REC
Set the auto-recording
function
PLAY SETTING Make playback settings
BROWSE
Work with files and folders
on the SD card
OTHERS
Open the OTHERS
submenu
INFORMATION View information
FILE NAME Make file name settings
DATE/TIME Set the date and time
SYSTEM Make system settings
Recording
Recording Screen
1 Monitoring mode
This shows what audio is now being monitored.
Indicator Meaning
MIX
Mix of channels 1-4,
or dual recording mode main file
SUB Dual recording mode sub file
1+2 Mix of channels 1-2
3+4 Mix of channels 3-4
CAM CAMERA IN jack sound input
CH1 Channel 1 sound input
1-M
Left channel of dual recording
mode main file
1-S
Left channel of dual recording
mode sub file
CH2 Channel 2 sound input
2-M
Right channel of dual recording
mode main file
2-S
Right channel of dual recording
mode sub file
