14
TASCAM DR-60DMKII
Indicator Meaning
CH3
Channel 3 sound input
3-M
Left channel of dual recording
mode main file
3-S
Left channel of dual recording
mode sub file
CH4 Channel 4 sound input
4-M
Right channel of dual recording
mode main file
4-S
Right channel of dual recording
mode sub file
2 Prerecording or Auto recording function
status
appears when the prerecording function is
ON, and in recording standby.
appears when the auto recording function
is ON, and recording.
3 Recording format
This shows the file recording format.
WAV16, WAV24, BWF16 or BWF24
4 Recording sampling frequency
This shows the file recording sampling
frequency.
44.1kHz, 48kHz or 96kHz
5 Elapsed recording time
The elapsed recording time of the file appears
as hours: minutes: seconds.
6 Number of recording channels
This shows the number of recording channels
in the file.
ST or MONO
7 Auto tone function status
No icon: Auto tone off
: Auto tone on
8 Recorder operation status
This icon shows the recorder operation status.
Indicator Meaning
09
Recording standby or Recording
paused
0 Recording
Self-timer recording activated
9 Input source
This icon shows the input source.
Indicators
(examples) Meaning
/ /
/
Mono recording mode input
source
/
Stereo recording mode input
source
/
Dual recording mode input
source and gain setting for the
second recording (0 to –12)
4-channel recording mode
input source
0 Recording level meters
The input signal level is shown.
q File name
The file name that will automatically be given
to the recorded file is shown.
w Remaining recording time
The remaining recording time on the SD card is
shown in hours: minutes: seconds according to
the recording mode, sampling frequency and
recording format settings.
e Low cut filter status
: Low cut filter off
: Low cut filter on
r Limiter function status
: Limiter off
: Limiter on
t SLATE button setting
: SLATE button disabled
: SLATE button enabled
y Peak value in decibels (dB)
Peak input level values are shown digitally.
