Unit repairs will not be subject to standard
unit warranties due to improper installation
procedures.
Electrical connection
Refer to the amperage data on page 3, the serial tag, your
local code or the National Electrical Code to be sure the unit is
connected to the proper power source. A protected circuit of
the correct voltage and amperage must be run for con nec tion
of the line cord, or permanent connection to the unit.
The on/off switch must be turned to OFF and
the unit disconnected from the power source
whenever performing service, maintenance
functions or cleaning the refrigerated area.
INSTALLATION
Location
Units represented in this manual are intended for indoor use
only. Be sure the location chosen has a floor strong enough
to support the total weight of the cabinet and contents. A fully
loaded unit can weigh as much as 4,000 pounds. Reinforce
the floor as necessary to provide for maximum loading. For
the most efficient refrigeration, be sure to provide good air
circulation inside and out.
Inside cabinet: Do not pack refrigerator so full that air
cannot circulate. The refrigerated air is discharged at the top
rear of the unit. It is important to allow for proper air flow
from the top rear to the bottom of the unit. Obstructions
to this air flow can cause evaporator coil freeze ups, loss of
temperature or overflow of water from the evaporator drain
pan. However, bags and other items can still be located to
the far rear of the cabinet. Air is
brought into the evaporator coil with
fans mounted to the front of the coil.
Prevent obstruction by locating large
boxes and tall stacks of product to
the bottom of the cabinet.
Outside cabinet: Be sure that
the unit has access to ample air.
Avoid hot corners and locations
near stoves and ovens. It is
recommended that the unit be
installed no closer than 2” from any
wall.
Leveling
A level cabinet will not be subject to undue stress and perform
better when the doors line up with the frames properly. Use
a level to make sure the unit is level from front to back and
side to side. When the unit is supplied with casters, no
adjustments are available, but if unit comes with legs, they
have adjustable bullet feet. Ensure the floor where the unit is
to be located is level.
Stabilizing
Models are supplied on casters for your convenience, ease
of cleaning underneath and for mobility. It is very important,
however, that the cabinet be installed in a stable condition
with the front wheels locked while in use.
