Specification line, Models

background image

Project __________________________________

Item ____________________________________

Quantity ________________________________

CSI Section 11400

Approved _______________________________

Date ____________________________________

980 S. Isabella Rd.
Mt. Pleasant, Michigan 48858

Phone: 800-733-8948 or 989-773-7981
Fax: 800-669-0619

www.delfield.com

Exterior: SS and SA models shall have corrosion resistant stainless
steel exterior cabinet sides, front and shroud. SM models shall have
corrosion resistant aluminum on exterior cabinet sides and will have
stainless front and shroud. All units shall have the upper shroud
hinged with a gas assist stay open feature to provide easy access to
the refrigeration system.

Interior: Cabinet interior shall be corrosion resistant stainless steel
(SS models) or heavy gauge aluminum (SA and SM models). Bottom
and top surfaces shall be die stamped to provide radius corners and
recessed floor. Three wire shelves are provided per section, SA/SS
standard shelves are chrome plated, SM standard shelves are epoxy
coated. Shelves rest on clips which are adjustable on 1” increments
on stainless steel pilasters affixed to the cabinet interior. Pilasters are
removable without tools for cleaning. Mounted to the interior ceiling
of each compartment, the interior incandescent lights are controlled
automatically through a switch mounted in the hinge assembly to
protect against breakage. Door openings are protected with heavy
gauge stainless steel breaker strips. An air duct shall be mounted to
the ceiling assuring low velocity, even air movement throughout the
cabinet interior.

Doors: Exterior shall be corrosion resistant stainless steel. Interior
liner shall be resilient high impact ABS material formed to protrude
beyond the door gasket to protect the gasket from tearing. Each door
has two edge mount, self closing, cam lift style hinges. Doors can be

removed from the cabinet without the use of tools. Metal door handle
shall be recessed into the door for easy grip without impacting aisle
space. Keyed door lock is mounted in the door next to the handle.
Lock engages into a heavy duty strike mounted to the cabinet face.
Door gaskets are magnetic and mount to the door snapping in place
and are removable without tools.

Refrigeration system: Each compartment has its own separate
refrigeration system. Condensing units are located on top of the
cabinet, outside the food zone, behind the removable upper shroud.
Evaporator coils are located inside the cabinet mounted to the interior
ceiling of each compartment. Defrost is automatic. Condensate
travels down a tube in the cabinet side wall to a receptacle mounted
to the exterior bottom of the cabinet where it is evaporated with
the aid of an electric heater. Each compartment’s temperature is
individually monitored and controlled using Delfield’s ACT-Advanced
Control Technology electronic temperature control, which provides
improved pull down times, reduces compressor cycling and longer
compressor life with lower energy consumption. Two exterior digital
thermometers display temperature. Refrigerator compartment
maintains between 33°F and 40°F. Freezer compartment maintains
temperature between -5ºF and 0ºF.

Electrical: Unit comes with one 10’ cord and plug with single point
connection to all cabinet and refrigeration system electronics. It is
attached to a junction box mounted on the exterior top of the cabinet.

Specifications

Standard Features

Options &
Accessories

• Stainless steel interior and exterior (SS)
• Stainless steel exterior, aluminum interior (SA)
• Aluminum interior and exterior, stainless front

(SM)

• Built in door locks with heavy duty strikes
• Recessed metal door handle
• Pressure relief valve is standard to prevent door

vapor lock

• Two exterior digital thermometers with high/

low temperature alarm

• Easy to use electronic control
• Easy access “flip up” shroud
• Three wire shelves per section - SA/SS standard

with chrome plated shelves and SM standard
with epoxy coated shelves

• Tough ABS interior door liners
• 10’ attached cord and plug
• 6” adjustable stainless steel legs
• Stainless steel breaker strips
• High density foamed in place environmentally

friendly, Kyoto Protocol Compliant, Non ODP
(Ozone Depletion Potential), Non GWP (Global
Warming Potential) polyurethane keeps energy
costs low

• Energy savings door heater switch
• Three year parts and labor warranty and an

additional two year compressor parts warranty

Full door

Half door

SSDRP2-S

SSDRP2-SH

Refrigerator left side stainless exterior and interior

SSDFP2-S

SSDFP2-SH

Freezer left side stainless exterior and interior

SADRP2-S

SADRP2-SH

Refrigerator left side stainless exterior and aluminum interior

SADFP2-S

SADFP2-SH

Freezer left side stainless exterior and aluminum interior

SMDRP2-S

SMDRP2-SH

Refrigerator left side stainless front aluminum exterior and interior

SMDFP2-S

SMDFP2-SH

Freezer left side stainless front aluminum exterior and interior

Models

Specification Line®

Self-Contained Solid Door Two-Section Dual Temp
Refrigerator/Freezer Pass-Thru

Specification Line® S

olid D

oor
Tw

o-S

ec

tion Dual

Temp R

efr

igerat

or/F
reez
er P
ass-
Thru

• Security (prison) package
• 6” polyurethane casters
• Door field rehingability
• Stainless steel interior door liner
• Additional shelves
• Tray slides
• Stainless steel back
• Laminate on front, sides and back
• Bottom mount electrical
• Stainless steel banking strip
• Heat shield end
• Stainless steel kick plate
• Laminate kick plate
• 4” stainless steel utility base
• 230-50-1 electrical*
• 220-60-1 electrical*

* Inclusion of these options will alter the

electrical specifications of unit

SSDFP2-S
