Project __________________________________

Item ____________________________________

Quantity ________________________________

CSI Section 11400

Approved _______________________________

Date ____________________________________

980 S. Isabella Rd.
Mt. Pleasant, Michigan 48858

Phone: 800-733-8948 or 989-773-7981
Fax: 800-669-0619

www.delfield.com

Exterior: SS and SA models shall have corrosion resistant stainless

steel exterior cabinet sides, front and shroud. SM models shall have

corrosion resistant aluminum on exterior cabinet sides and will have

stainless front and shroud. All units shall have the upper shroud

hinged with a gas assist stay open feature to provide easy access to

the refrigeration system.

Interior: Cabinet interior shall be corrosion resistant stainless steel

(SS models) or heavy gauge aluminum (SA and SM models). Bottom

and top surfaces shall be die stamped to provide radius corners

and recessed floor. Four wire shelves are provided, SA/SS standard

shelves are chrome plated, SM standard shelves are epoxy coated.

Shelves rest on clips which are adjustable on 1” increments on

stainless steel pilasters affixed to the cabinet interior. Pilasters are

removable without tools for cleaning. Mounted to the interior ceiling

of each compartment, the interior fluorescent lights are controlled

automatically through a switch mounted in the hinge assembly to

protect against breakage. Door openings are protected with heavy

gauge stainless steel breaker strips. An air duct shall be mounted to

the ceiling assuring low velocity, even air movement throughout the

cabinet interior.

Doors: Glass door models have a glass doors on one side and

solid doors on the other. Double paned tempered thermopane

glass. Constructed with a combination of extruded aluminum and

PVC. Each door has two edgemount, self-closing, cam lift style

hinges. Doors can be removed from the cabinet without the use of

tools. Door handle is continuous along vertical dimension of the

door. Door gaskets are magnetic and mount to the door, snapping

in place and removable with out tools. Keyed door lock is mounted

to the door. Lock engages into a heavy duty strike mounted to the

cabinet face.

Refrigeration system: Each compartment has its own separate

refrigeration system. Condensing units are located on top of the

cabinet, outside the food zone, behind the removable upper

shroud. Evaporator coils are located inside the cabinet mounted

to the interior ceiling of each compartment. Defrost is automatic.

Condensate travels down a tube in the cabinet side wall to a

receptacle mounted to the exterior bottom of the cabinet where it

is evaporated with the aid of an electric heater. Each compartment’s

temperature is individually monitored, controlled and displayed on

the exterior of the cabinet. Refrigerator compartment maintains

between 33°F and 41°F. Freezer compartment maintains temperature

between 0ºF and -5ºF.

Electrical: Unit comes with one 10’ cord and plug with single point

connection to all cabinet and refrigeration system electronics. It

is attached to a junction box mounted on the exterior top of the

cabinet.

Specifications

Standard Features

Options &
Accessories

Stainless steel interior and exterior (SS)
Stainless steel exterior, aluminum interior (SA)
Aluminum interior and exterior, stainless front
(SM)
Built in door locks with heavy duty strikes
Recessed metal door handle
Pressure relief valve is standard to prevent door
vapor lock
Two exterior digital thermometers with high/
low temperature alarm
Easy to use electronic control
Easy access “flip up” shroud
Four wire shelves - SA/SS standard with chrome
plated shelves and SM standard with epoxy
coated shelves
10’ attached cord and plug
6” adjustable stainless steel legs
Stainless steel breaker strips
High density foamed in place environmentally
friendly, Kyoto Protocol Compliant, Non ODP
(Ozone Depletion Potential), Non GWP (Global
Warming Potential) polyurethane keeps energy
costs low
Energy savings door heater switch
Two year parts & labor warranty
Five year compressor warranty












SSDTP1-GH

Refrigerator top/freezer bottom stainless exterior and interior glass half door

SSDBP1-GH

Freezer top/refrigerator bottom stainless exterior and interior glass half door

SADTP1-GH

Refrigerator top/freezer bottom stainless exterior and aluminum interior glass half door

SADBP1-GH

Freezer top/refrigerator bottom stainless exterior and aluminum interior glass half door

SMDTP1-GH

Refrigerator top/freezer bottom stainless front aluminum exterior and interior glass half door

SMDBP1-GH

Freezer top/refrigerator bottom stainless front aluminum exterior and interior glass half door

Models

Specification Line®

Glass Door Single Section Dual Temp Refrigerator/
Freezer Pass-Thru Units

Specification Line®: Glass Door Single Section Dual Temp Refrigerator/Fr

eezer Pass-Thru Units

Security (prison) package
Incandescent light
Door field rehingability
Additional shelves
Tray slides
Stainless steel back
Laminate on front, sides and back
Bottom mount electrical
Stainless steel banking strip
Heat shield end
Stainless steel kick plate
Laminate kick plate
4” stainless steel utility base
230-50-1 electrical
220-60-1 electrical















SSDBP1-GH
