Delfield UCD4464N User Manual

Uc4464n undercounter, Front-breathing undercounter refrigerators

background image

UC4464N FRONT

-BREA

THING UNDERCOUNTER REFRIGERA

TORS

Project __________________________

Item ____________________________

Quantity _________________________

CSI Section 11400

UC4464N UNDERCOUNTER

Front-Breathing Undercounter Refrigerators

980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfi eld.com

Phone: 800-733-8948
Fax: 800-669-0619
Email: info@delfi eld.com

Approval _________________

Date ____________________

MODELS:

UC4464N

Two section refrigerator

UCD4464N

Two section refrigerator

Undercounter with a door

Undercounter with drawers

Model UC4464N

SPECIFICATIONS

Exterior top is one-piece, 22-gauge stainless steel with

integral square nosing on the front.

Exterior back and bottom are two-piece 24-gauge

galvanized steel.

Exterior ends are stainless steel.

Interior sides of door models are thermoformed ABS

plastic with integral shelves supports. Interior back is one-
piece 22-gauge stainless steel. Interior bottom and top
are thermoforned ABS plastic. Base is fully insulated with
high-density foamed in place polyurethane.

Refrigeration system uses HFC-404A refrigerant.

Compressor is 1/5 H.P., with condenser coil and

condensate evaporator mounted on rear of the cabinet.

Evaporator coil are located on the interior rear wall of

the cabinet. Refrigerant flow is controlled by a capillary

tube. Cabinet maintains an interior cabinet temperature of

36°F to 40°F (2°C to 4°C).

ACT control. ACT electronic, solid state control, mounted

on the exterior rear of the cabinet, allows unit to maintain
precise temperatures in heavy duty conditions.

Electrical connections are 115 volt, 60 Hertz, single

phase. Unit has a 7’ (2.1m) long electrical cord and NEMA

5-15P plug.

Casters: Equipment is mounted on 2” (5.08cm) diameter

front locking plate casters. 2.5” (6.35cm) ride height.

Doors have a 24-gauge stainless steel exterior, with

thermoformed ABS plastic interior liner. Cabinet of door

models has one adjustable epoxy-coated wire shelf.

Drawers have a 24-gauge stainless steel exterior

with thermoformed ABS plastic interior liner. Drawer

frames are 12-gauge stainless steel. Drawer slides are

11-gauge stainless steel with Delrin bearings. Drawer

units have two drawers. Top drawer holds one 12” x

20” (30.5cm x 50.8cm x 10.1cm) and three 1/6 size

4"-6" deep pans. Bottom drawer holds one 12" x 20"

and three 1/6 size 4" deep pans. Pans are supplied

by others.

STANDARD FEATURES

• All 4400 and 4500 Series units are 100% front

breathing, which allows the unit to be pushed against
a wall or built into a cabinet or an existing line up

• Durable, rugged stainless steel sides, top and front
• Features Delfi eld’s exclusive ABS interior (on sides).

ABS is extremely durable - it won’t dent, chip or
corrode and is backed by a limited lifetime warranty

• Heavy duty self-closing hinges
• “D” prefi x models feature Delfi eld’s exclusive new

drawer system. Drawers are backed by a 10-year
warranty on the track assembly

• Environmentally friendly R404A refrigerant
• High density foamed in place polyurethane keeps

energy costs low

• Black recessed quick grip handle
• Standard on 2” casters for easy cleaning and

installation

• 60-cycle single phase electrical system
• 7’ cord and plug supplied
• Cord spring relief - prevents cord rollover
• One epoxy coated wire shelf standard, installed per

door section

• ACT solid state electronic control
• One year parts and 90 day labor standard warranty.

OPTIONS AND ACCESSORIES

Flat lift off cover

18” wide single tier overshelf

Stainless steel finish on back

Plastic laminate on front

Additional wire shelves

Door lock

Exterior thermometer

Interior lights

Glass door(s)

*220V/50 Hertz electrical system

* Inclusion of this option will alter electrical

specifications of the unit.
