ColdPro Service and Installation Manual
For customer service, call (800) 733-8829, (800) 733-8821, Fax (989) 773-3210, www.delfi eld.com
13
REPLACEMENT PARTS
MISC. ITEMS
DESCRIPTION
SPEC.
TOP SHROUD COVER HOLD DOWN SCREW
M4, 16MM LONG (NICKEL GALVANIZED)
TOP SHROUD HINGE SCREW & NUTS
M4, 16MM LONG (STAINLESS STEEL), M4 NUT (STAINLESS STEEL)
M4, 10MM LONG (ZINC GALVANIZED)
CABINET HINGE MOUNTING SCREW
M6, 20MM LONG (STAINLESS STEEL)
LOWER SHROUD MOUNTING SCREW
M4, 10MM LONG (ZINC GALVANIZED)
REAR MACHINE COMPARTMENT MOUNTING SCREW
M5, 20MM LONG (ZINC GALVANIZED)
HINGE CARTRIDGE MOUNTING SCREW
M5, 20MM LONG (STAINLESS STEEL)
HINGE CARTRIDGE PIN SCREW
M5, 10MM LONG (STAINLESS STEEL)
EVAPORATOR HOUSING MOUNTING SCREW
M4, 16MM LONG (STAINLESS STEEL)
EVAPORATOR FAN GUARD MOUNTING SCREW
M5, 10MM LONG (STAINLESS STEEL), M5 NUT (STAINLESS STEEL)
EVAPORATOR FAN MOTOR MOUNTING SCREW
M4, 16MM LONG (STAINLESS STEEL), M4 NUT (STAINLESS STEEL)
REFRIGERATOR VINYL DRAIN TUBE
0.625 OD, 0.5O ID
FREEZER VINYL DRAIN TUBE
0.375 OD, 0.25 ID
PART NUMBER
DESCRIPTION
UNIT TYPE
1 DR REF
2 DR REF
3 DR REF
1 DR FRZ
2 DR FRZ
3 DR FRZ
123-BEI-0030
SUCTION LINE COVER
X
X
X
123-BEI-0031
SUCTION LINE COVER
X
X
X
3516338
THERMOMETER
X
X
X
X
X
X
9321593
THERMOMETER BULB CLIP
X
X
X
X
X
X
127-BXV-0040
THERMOMETER TRANSFORMER BRACKET
X
X
X
X
X
X
2194673
THERMOSTAT
X
X
X
3516336
THERMOSTAT
X
X
X
MODEL
1 DR REF
2 DR REF
3 DR REF
1 DR FRZ
2 DR FRZ
3 DR FRZ
START RELAY MANUFACTURER AND MODEL (OR EQUIVALENT)
ELECTRICA
MTRP 5508
W343
ELECTRICA
MTRP
H0016
-08W343
KLIXON
9660-3027-
19109
Z3L
KLIXON
9660C-041-
191 21 V2L
GENERAL
ELECTRIC
3ARR383F3
GENERAL
ELECTRIC
3ARR3B3S3
START CAPACITOR RATING (uF)
145-174
189-227
189-227
145-175
145-174
340-408
START CAPACITOR VOLTAGE RATING (VAC)
165
165
330
250
165
165
RUN CAPACITOR RATING (uF)
NONE USED
NONE USED
NONE USED
NONE USED
25 ± 5%
20 ± 5%
The installation of generic replacement parts will VOID warranty.
