3.4.7 ADCs Output Format GroupA – 0x13
ADCs Output Format GroupA – 0x13 (Read-Write register).
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
1 Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
Default ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’
0 Reserved Reserved Reserved Reserved Reserved Reserved Output
Format
bit1
Output
Format
bit0
Default ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’
ADCs Output Format GroupA – 0x13 (Read-Write register).
Setting Bit 1:0 Description - Output Format GroupA - ADC0...5
0 00 For Calibration routine.
1 01 Two’s complement samples - capture.
2 10 Binary samples - capture.
3 11 Zeroes.
3.4.8 ADCs Output Format GroupB – 0x14
ADCs Output Format GroupB – 0x14 (Read-Write register).
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
1 Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
Default ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’
0 Reserved Reserved Reserved Reserved Reserved Reserved Output
Format
bit1
Output
Format
bit0
Default ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’
ADCs Output Format GroupB – 0x14 (Read-Write register).
Setting Bit 1:0 Description - Output Format GroupB - ADC0...5
0 00 For Calibration routine
1 01 Two’s complement samples - capture.
2 10 Binary samples - capture.
3 11 Zeroes.
3.4.9 Led Register – 0x15
There are 12 LEDs on the SMT916 controlled by a register. They are controlled
individually by writing ones or zeroes in this register.
