48-466 Operators Manual 11
CHAPTER 3: COMMUNICATIONS
The 48-466 can be interfaced to PC's, mini-computers, main frames, and special purpose
machines. It is capable of serial RS-232-C or Centronics® parallel communication. The
following sections explain the communication interfaces.
Out of the box, unless otherwise requested, the 48-466 communicates using either parallel or
serial RS-232-C at 9600 baud, 8 data bits, 1 stop bit and no parity with both hardware and
software handshaking. This configuration may be changed as shown in Appendix B.
3.1 CABLE PINOUT
Table 1 shows the signals of the 25-pin RS-232 serial port and table 2 shows the parallel port
configuration.
If serial RS-232-C communication is selected and XON/XOFF hand shaking is used, the only
signals the 48-466 requires are the RXD, TXD, and GND signals. If hardware (CTS/RTS) hand
shaking is used a RTS signal is provided. XON/XOFF may be disabled through software dip
switch #1 (see chapter 5). The other signals are offered in the event the host computer requires
these signals.
Serial Port Configuration
25 TO 9 PIN 25 TO 25 PIN
State 466 Direction PC
HI 8 DCD ---->---- DCD 1
XX 3 TXD ---->---- RXD 2
XX 2 RXD ----<---- TXD 3
HI 6 DSR ----<---- DTR 4
LO 7 GND ---<->--- GND 5
HI 20 DTR ---->---- DSR 6
DC 4 CTS ----<---- RTS 7
XX 5 RTS ---->---- CTS 8
HI 18 +5V
DB-25 DE-9
DC = Do Not Care
XX = Indeterminate
State 466 Direction PC
HI 8 DCD ---->---- DCD 8
XX 3 TXD ---->---- RXD 3
XX 2 RXD ----<---- TXD 2
HI 6 DSR ----<---- DTR 20
LO 7 GND ---<->--- GND 7
HI 20 DTR ---->---- DSR 6
DC 4 CTS ----<---- RTS 4
XX 5 RTS ---->---- CTS 5
HI 18 +5V
DB-25 DB-25
DC = Do Not Care
XX = Indeterminate
Table 1
