Figure 3-17 Status Label (Examples)

3.14 TOF Sensor

The TOF Sensor is used to detect when media is present and is used in conjunction with the
Top-Of-Form operation. A TOF is when the printer uses the sensor to detect the edge of
the media and retracts the configured distance. See the D121 and D123 commands for
more details regarding the TOF operation.

A potentiometer adjusts the distance over which the LPD sensor will detect reflections. The
maximum range may be adjusted over a distance of 0.20” to 0.85”. Distances are
measured from the surface of the sensor to the reflecting surface. The sensor is set to the
maximum detection at the factory. This pot may be used to decrease sensor range to avoid
false reflections from stationary objects such as a cutter.

PRINTER SERIAL #: 00516645051

PRINTED LABELS: 303

PRINTED INCHES: 1533

TOTAL INCHES: 1571

POWER ON HOURS: 32.8

CUTTER TYPE: Guillotine

CUTTER ENABLED?: YES

CUTTER COUNTS: 1789

KIOSK CUT MODE: Disabled

KIOSK DISTANCE: 0

SWITCH BANK 1: 10001010
SWITCH BANK 2: 01010001
SWITCH BANK 3: 00000000
SWITCH BANK 4: 00000000
SWITCH BANK 5: 00000000
SWITCH BANK 6: 00000001

CURRENT COMM PORT: Autoselect USB/RS232

RS232 PARAMETERS: 115200-N-8-1

PRINT HEAD SIZE: 1280

PRINT HEAD DPI: 300

% CONTRAST: 100

D91 GAP VALUE: 30

TOF DISTANCE: 179

STOCK OUT VALUE: 100

PRINTER CODE REV: 02.12.050719A

BOOTLOADER CODE REV: 02.12.050719A

CODE ASSY PN. 071001-0212
